Specifications
Order Number:
| model & size | color temp | finish | led watts | led lumens | delivered lumens |
|---|---|---|---|---|---|
| WS109614 - 14" | 2700K/3000K/3500K/4000K | BC - Black Chrome | 29W | 1698 | 1454 |
| WS109620 - 20" | 2700K/3000K/3500K/4000K | BC - Black Chrome | 35.3W | 3655 | 1895 |
Features
- Delivered Lumens: Up to 1895lm
- CCT: 2700K/3000K/3500K/4000K
- CRI: 90
- Power: 29W, 35.3W
- Input: 120-277V, 50/60Hz
- ELV Dimming: 100-10%
- TRIAC Dimming: 100-10%
- Rated Life: 50000 Hours
- Construction: Metal frame with acrylic diffuser
- Built in color temperature adjustability. Switch from 2700K/3000K/3500K/4000K
- Driver concealed within the canopy
- Can be mounted on wall and ceiling in all orientations
- Can be mounted on ceiling or wall in all orientations
Line Drawing
