Specifications
Order Number:
| model & voltage | color temp & cri | finish | lumens |
|---|---|---|---|
| WP-LED119 - 120-277 VAC | 3000K - 85 | ABZ - Architectural Bronze | 1390 |
| WP-LED119 - 120-277 VAC | 3000K - 85 | AGH - Architectural Graphite | 1390 |
| WP-LED119 - 120-277 VAC | 3000K - 85 | AWT - Architectural White | 1390 |
| WP-LED127 - 120-277 VAC | 3000K - 85 | ABZ - Architectural Bronze | 2075 |
| WP-LED127 - 120-277 VAC | 3000K - 85 | AGH - Architectural Graphite | 2075 |
| WP-LED127 - 120-277 VAC | 3000K - 85 | AWT - Architectural White | 2075 |
| WP-LED135 - 120-277 VAC | 3000K - 85 | ABZ - Architectural Bronze | 2750 |
| WP-LED135 - 120-277 VAC | 3000K - 85 | AGH - Architectural Graphite | 2750 |
| WP-LED135 - 120-277 VAC | 3000K - 85 | AWT - Architectural White | 2750 |
Features
- Delivered Lumens: Up to 2750lm
- CBCP: Up to 1930
- CCT: 3000K
- CRI: 85
- Power: 19W, 27W, 35W
- Input: 120-277 VAC, 50/60Hz
- ELV Dimming: 100-15%
- 0-10V Dimming: 100-30%
- Rated Life: 100000 Hours
- Construction: Die-cast aluminum
- Factory sealed LED Light Engine
- 20° forward throw illumination
- Photo/motion sensor compatible (sold separately)
- Built-in level for easy adjustment
- Suitable to install in all directions
- Driver concealed within the fixture
Line Drawing
