FQ 2″ New Const Housing Millwork, Round and Square

NEW

Order Number:

model	ceiling thickness	power	description
R2FRNM - Round	A - 0.25in to 0.75in	1 - 15W	FQ 2" New Construction Housing Round 0.8in Millwork 15W IC
R2FRNM - Round	A - 0.25in to 0.75in	2 - 21W	FQ 2" New Construction Housing Round 0.8in Millwork 21W IC
R2FRNM - Round	A - 0.25in to 0.75in	3 - 25W	FQ 2" New Construction Housing Round 0.8in Millwork 25W Non-IC
R2FRNM - Round	B - 0.75in to 1.5in	1 - 15W	FQ 2" New Construction Housing Round 1.5in Millwork 15W IC
R2FRNM - Round	B - 0.75in to 1.5in	2 - 21W	FQ 2" New Construction Housing Round 1.5in Millwork 21W IC
R2FRNM - Round	B - 0.75in to 1.5in	3 - 25W	FQ 2" New Construction Housing Round 1.5in Millwork 25W Non-IC
R2FSNM - Square	A - 0.25in to 0.75in	1 - 15W	FQ 2" New Construction Housing Square 0.8in Millwork 15W IC
R2FSNM - Square	A - 0.25in to 0.75in	2 - 21W	FQ 2" New Construction Housing Square 0.8in Millwork 21W IC
R2FSNM - Square	A - 0.25in to 0.75in	3 - 25W	FQ 2" New Construction Housing Square 0.8in Millwork 25W Non-IC
R2FSNM - Square	B - 0.75in to 1.5in	1 - 15W	FQ 2" New Construction Housing Square 1.5in Millwork 15W IC
R2FSNM - Square	B - 0.75in to 1.5in	2 - 21W	FQ 2" New Construction Housing Square 1.5in Millwork 21W IC
R2FSNM - Square	B - 0.75in to 1.5in	3 - 25W	FQ 2" New Construction Housing Square 1.5in Millwork 25W Non-IC

Power: 15W, 21W, 25W
Input: 120-277 VAC, 50/60Hz
Airtight
ELV Dimming: 100-1%
0-10V Dimming: 100-1%
TRIAC Dimming: 100-1%
Construction: 20 gauge galvanized steel
Housings are supplied with millwork collar for use with wood and millwork depths up to 1.5in thickness
Quick connectors installed on driver for easy driver replacement
Compatible with Downlight, Adjustable, Pinhole, and Wall Wash trimless for new construction millwork applications.
Square housings feature 20 degree lateral adjustment range for trims
Driver concealed within the fixture
