Specifications
Order Number:
| model | color temp & cri | max lumens | max cbcp | power | finish |
|---|---|---|---|---|---|
| R2FRPT-TWA | TWA - 1800K-4000K - 90 | 510 | 2360 | 14W, 18W | BK - Black |
| R2FRPT-TWA | TWA - 1800K-4000K - 90 | 510 | 2360 | 14W, 18W | DB - Dark Bronze |
| R2FRPT-TWA | TWA - 1800K-4000K - 90 | 510 | 2360 | 14W, 18W | WT - White |
Features
- Delivered Lumens: 510lm
- CBCP: 2360
- CCT: 1800K-4000K
- CRI: 90
- Power: 14W, 18W
- Rated Life: 50000 Hours
- Construction: Durable die-cast aluminum trim with aluminum heat sink
- Operating Temp: -4°F to 104°F (-20°C to 40°C)
- Two-piece die-cast construction
- Light engine mounted on trim with springs for easy replacement
- Accepts one Lens or glare control accessory
- Refer to specification sheet for lumens and CBCP data
Line Drawing
