FQ 2″ Tunable White New Const Housing Millwork, Round and Square

NEW

NEW

Order Number:

model	ceiling thickness	color temp	power	description
R2FRNM - Round	A - 0.25in to 0.75in	TW - Tunable White	1 - 14W	FQ 2" TW New Construction Housing Round 0.75in Millwork 14W IC
R2FRNM - Round	A - 0.25in to 0.75in	TW - Tunable White	2 - 18W	FQ 2" TW New Construction Housing Round 0.75in Millwork 18W IC
R2FRNM - Round	B - 0.75in to 1.5in	TW - Tunable White	1 - 14W	FQ 2" TW New Construction Housing Round 1.5in Millwork 14W IC
R2FRNM - Round	B - 0.75in to 1.5in	TW - Tunable White	2 - 18W	FQ 2" TW New Construction Housing Round 1.5in Millwork 18W IC
R2FSNM - Square	A - 0.25in to 0.75in	TW - Tunable White	1 - 14W	FQ 2" TW New Construction Housing Square 0.75in Millwork 14W IC
R2FSNM - Square	A - 0.25in to 0.75in	TW - Tunable White	2 - 18W	FQ 2" TW New Construction Housing Square 0.75in Millwork 18W IC
R2FSNM - Square	B - 0.75in to 1.5in	TW - Tunable White	1 - 14W	FQ 2" TW New Construction Housing Square 1.5in Millwork 14W IC
R2FSNM - Square	B - 0.75in to 1.5in	TW - Tunable White	2 - 18W	FQ 2" TW New Construction Housing Square 1.5in Millwork 18W IC

CCT: Tunable White
Power: 14W, 18W
Input: 120-277 VAC, 50/60Hz
Airtight
Rated Life: 50000 Hours
Construction: 20 gauge galvanized steel
Housings are supplied with millwork collar for use with wood and millwork depths up to 1.5in thickness
Quick connectors installed on driver for easy driver replacement
Compatible with Downlight, Adjustable, Pinhole, and Wall Wash trimless for new construction millwork applications.
Square housings feature 20 degree lateral adjustment range for trims
Driver concealed within the fixture
