InvisiLED® CCT Color Temperature Selectable LED Tape

Specifications

Order Number:
model size color temp & cri finish watt lumens
T24-CS1 1' 2750 - 2700K/3000K/3500K/4000K/5000K - 95 WT - WHITE 1.2W/ft 100/ft
T24-CS1 5' 2750 - 2700K/3000K/3500K/4000K/5000K - 95 WT - WHITE 1.2W/ft 100/ft
T24-CS1 10' 2750 - 2700K/3000K/3500K/4000K/5000K - 95 WT - WHITE 1.2W/ft 100/ft
T24-CS1 20' 2750 - 2700K/3000K/3500K/4000K/5000K - 95 WT - WHITE 1.2W/ft 100/ft
T24-CS1 60' 2750 - 2700K/3000K/3500K/4000K/5000K - 95 WT - WHITE 1.2W/ft 100/ft
T24-CS10 1' 2750 - 2700K/3000K/3500K/4000K/5000K - 95 WT - WHITE 8.5W/ft 1000/ft
T24-CS10 5' 2750 - 2700K/3000K/3500K/4000K/5000K - 95 WT - WHITE 8.5W/ft 1000/ft
T24-CS10 10' 2750 - 2700K/3000K/3500K/4000K/5000K - 95 WT - WHITE 8.5W/ft 1000/ft
T24-CS2 1' 2750 - 2700K/3000K/3500K/4000K/5000K - 95 WT - WHITE 2.4W/ft 200/ft
T24-CS2 5' 2750 - 2700K/3000K/3500K/4000K/5000K - 95 WT - WHITE 2.4W/ft 200/ft
T24-CS2 10' 2750 - 2700K/3000K/3500K/4000K/5000K - 95 WT - WHITE 2.4W/ft 200/ft
T24-CS2 20' 2750 - 2700K/3000K/3500K/4000K/5000K - 95 WT - WHITE 2.4W/ft 200/ft
T24-CS2 40' 2750 - 2700K/3000K/3500K/4000K/5000K - 95 WT - WHITE 2.4W/ft 200/ft
T24-CS3 1' 2750 - 2700K/3000K/3500K/4000K/5000K - 95 WT - WHITE 3W/ft 300/ft
T24-CS3 5' 2750 - 2700K/3000K/3500K/4000K/5000K - 95 WT - WHITE 3W/ft 300/ft
T24-CS3 10' 2750 - 2700K/3000K/3500K/4000K/5000K - 95 WT - WHITE 3W/ft 300/ft
T24-CS3 20' 2750 - 2700K/3000K/3500K/4000K/5000K - 95 WT - WHITE 3W/ft 300/ft
T24-CS3 30' 2750 - 2700K/3000K/3500K/4000K/5000K - 95 WT - WHITE 3W/ft 300/ft
T24-CS4 1' 2750 - 2700K/3000K/3500K/4000K/5000K - 95 WT - WHITE 4.6W/ft 400/ft
T24-CS4 5' 2750 - 2700K/3000K/3500K/4000K/5000K - 95 WT - WHITE 4.6W/ft 400/ft
T24-CS4 10' 2750 - 2700K/3000K/3500K/4000K/5000K - 95 WT - WHITE 4.6W/ft 400/ft
T24-CS4 20' 2750 - 2700K/3000K/3500K/4000K/5000K - 95 WT - WHITE 4.6W/ft 400/ft
T24-CS6 1' 2750 - 2700K/3000K/3500K/4000K/5000K - 95 WT - WHITE 6.3W/ft 600/ft
T24-CS6 5' 2750 - 2700K/3000K/3500K/4000K/5000K - 95 WT - WHITE 6.3W/ft 600/ft
T24-CS6 10' 2750 - 2700K/3000K/3500K/4000K/5000K - 95 WT - WHITE 6.3W/ft 600/ft
T24-CS6 15' 2750 - 2700K/3000K/3500K/4000K/5000K - 95 WT - WHITE 6.3W/ft 600/ft

Features

  • CCT: 2700K/3000K/3500K/4000K/5000K
  • CRI: 95
  • Power: 1.2W/ft, 2.4W/ft, 3W/ft, 4.6W/ft, 6.3W/ft, 8.5W/ft
  • Input: 24 VDC
  • Rated Life: 50000 Hours
  • May be cut and easily reconnected every 4 inches
  • Select and choose desirable CCT with matching CCT selectable power supply
  • UV stabilized protective coating protects LEDs and circuitry for long term use in Damp Locations
  • Connections may be separated and reconnected at each junction point
  • Equal brightness for an entire light strip
  • Strong adhesive bonding with the 3M adhesive VHB
  • Gold plated connector protects from corrosion, heat, and ensures a reliable electrical connection
  • 100ft max distance between the power supply and beginning of InvisiLED®
  • Can be mounted on ceiling or wall in all orientations
