Specifications
Order Number:
| model & size | color temp | finish | led watts | led lumens | delivered lumens |
|---|---|---|---|---|---|
| WS-W33516 - 16" | 2700K | BK - Black | 13W | 1000 | 670 |
| WS-W33516 - 16" | 3000K | BK - Black | 13W | 1000 | 670 |
| WS-W33516 - 16" | 3500K | BK - Black | 13W | 1000 | 670 |
| WS-W33516 - 16" | 4000K | BK - Black | 13W | 1000 | 670 |
| WS-W33525 - 25" | 2700K | BK - Black | 19W | 1515 | 1033 |
| WS-W33525 - 25" | 3000K | BK - Black | 19W | 1515 | 1033 |
| WS-W33525 - 25" | 3500K | BK - Black | 19W | 1515 | 1033 |
| WS-W33525 - 25" | 4000K | BK - Black | 19W | 1515 | 1033 |
| WS-W33534 - 34" | 2700K | BK - Black | 25W | 1996 | 1491 |
| WS-W33534 - 34" | 3000K | BK - Black | 25W | 1996 | 1491 |
| WS-W33534 - 34" | 3500K | BK - Black | 25W | 1996 | 1491 |
| WS-W33534 - 34" | 4000K | BK - Black | 25W | 1996 | 1491 |
Features
- Delivered Lumens: Up to 1491lm
- CCT: 2700K, 3000K, 3500K, 4000K
- CRI: 90
- Power: 13W, 19W, 25W
- Input: 120, 50/60Hz
- ELV Dimming: 100-10%
- TRIAC Dimming: 100-10%
- Rated Life: 54000 Hours
- Construction: Aluminum hardware
- Built in color temperature adjustability. Switch from 2700K/3000K/3500K/4000K
- Option to pre-select color temperature or adjust in the field
- Light engine is factory sealed for maximum protection from the elements
- Weather resistant powder coated finish
- ACLED driverless technology
Line Drawing
