Specifications
Order Number:
| model & size | color temp | finish | led watts | led lumens | delivered lumens |
|---|---|---|---|---|---|
| WS-W17524 - 24" | 2700K | BK - Black | 30W | 2825 | 685 |
| WS-W17524 - 24" | 3000K | BK - Black | 30W | 2825 | 685 |
| WS-W17524 - 24" | 3500K | BK - Black | 30W | 2825 | 685 |
| WS-W17524 - 24" | 4000K | BK - Black | 30W | 2825 | 685 |
| WS-W17532 - 32' | 2700K | BK - Black | 44W | 4087 | 925 |
| WS-W17532 - 32' | 3000K | BK - Black | 44W | 4087 | 925 |
| WS-W17532 - 32' | 3500K | BK - Black | 44W | 4087 | 925 |
| WS-W17532 - 32' | 4000K | BK - Black | 44W | 4087 | 925 |
Features
- Delivered Lumens: Up to 925lm
- CCT: 2700K, 3000K, 3500K, 4000K
- CRI: 90
- Power: 30W, 44W
- Input: 120, 50/60Hz
- ELV Dimming: 100-10%
- TRIAC Dimming: 100-10%
- Rated Life: 50000 Hours
- Construction: Aluminum hardware
- Built in color temperature adjustability. Switch from 2700K/3000K/3500K/4000K
- Option to pre-select color temperature or adjust in the field
- Light engine is factory sealed for maximum protection from the elements
- Weather resistant powder coated finish
- ACLED driverless technology
- Can be mounted on wall in all orientations
Line Drawing
