Specifications Limited Availability, Consult Factory
Limited Availability, Consult Factory
Order Number:
model & size | color temp & cri | finish | watt | voltage | led lumens | delivered lumens |
---|---|---|---|---|---|---|
WS-12712 - 12" | 3000K - 90 | PN - Polished Nickel | 11W | 120-277V | 858 | 418 |
WS-12713 - 13" | 3000K - 90 | PN - Polished Nickel | 8W | 120 VAC | 392 | 139 |
WS-12718 - 18" | 3000K - 90 | PN - Polished Nickel | 16W | 120 VAC | 771 | 333 |
WS-12724 - 24" | 3000K - 90 | PN - Polished Nickel | 16W | 120 VAC | 730 | 326 |
Features
- Delivered Lumens: 418lm
- CCT: 3000K
- CRI: 90
- Power: 8W, 11W, 16W
- Input: 120 VAC, 120-277V, 277 VAC, 50/60Hz
- ELV Dimming: 100-10%
- Rated Life: 50000 Hours
- Construction: Aluminum hardware with seedy glass diffuser
- One-inch thick solid crystal with bubbles
- Up & down light
- Junction box conceals a proprietary universal 120V-220V-277V driver (12”)
- ACLED driverless technology (13”, 18” & 24”) with 277V special order
- 0-10V dimming option (LDS065M010AFE-LO1) available (special order), unit dimensions: 3.4" x 1.2" x 0.5"
- Driver installed within the Junction Box, driver dimension: 2.8" x 1.3" x 1.2"
- Can be mounted on wall vertically or upside down
- For 277V special order, add an "F" before the finish: WS-12713F-PN
