Specifications
Order Number:
| model & size | color temp | finish | led watts | led lumens | delivered lumens |
|---|---|---|---|---|---|
| PD-15514 - 14" | 3000K | BK - Black | 21W | 700 | 432 |
| PD-15514 - 14" | 3000K | BN - Brushed Nickel | 22W | 700 | 430 |
| PD-15514 - 14" | 3500K | BK - Black | 21W | 700 | 432 |
| PD-15514 - 14" | 5000K | BN - Brushed Nickel | 22W | 700 | 430 |
| PD-15514 - 14" | 4000K | BK - Black | 21W | 700 | 432 |
| PD-15514 - 14" | 3500K | BN - Brushed Nickel | 22W | 700 | 430 |
| PD-15514 - 14" | 5000K | BK - Black | 21W | 700 | 432 |
| PD-15514 - 14" | 4000K | BN - Brushed Nickel | 22W | 700 | 430 |
Features
- Delivered Lumens: Up to 432lm
- CCT: 3000K, 3500K, 4000K, 5000K
- CRI: 90
- Power: 21W, 22W
- Input: 120-277V, 50/60Hz
- ELV Dimming: 100-10%
- 0-10V Dimming: 100-10%
- TRIAC Dimming: 100-10%
- Rated Life: 50000 Hours
- Construction: Aluminum body with K5 crystal
- Built in color temperature adjustability. Switch from 3000K/3500K/4000K/5000K
- Option to pre-select color temperature or adjust in the field
- Rotatable K5 Crystal
- May be mounted on a sloped ceiling
Line Drawing
