Specifications
Order Number:
| model & size | power | watt | beam | color temp & cri | delivered lumens | cbcp | finish |
|---|---|---|---|---|---|---|---|
| S2SA | 1 | 17W | F - 42° | TWA - 1800-4000K - 90 | 1090 | 2100 | BK - Black |
| S2SA | 1 | 17W | F - 42° | TWA - 1800-4000K - 90 | 1090 | 2100 | WT - White |
| S2SA | 1 | 17W | N - 32° | TWA - 1800-4000K - 90 | 960 | 2590 | BK - Black |
| S2SA | 1 | 17W | N - 32° | TWA - 1800-4000K - 90 | 960 | 2590 | WT - White |
| S2SA | 1 | 17W | W - 60° | TWA - 1800-4000K - 90 | 1010 | 1120 | BK - Black |
| S2SA | 1 | 17W | W - 60° | TWA - 1800-4000K - 90 | 1010 | 1120 | WT - White |
Features
- Delivered Lumens: Up to 1090lm
- CBCP: Up to 2590
- CCT: 1800-4000K
- CRI: 90
- Power: 17W
- Input: 48 VDC
- ELV Dimming: 100-0.1%
- 0-10V Dimming: 100-0.1%
- TRIAC Dimming: 100-0.1%
- DMX Dimming: 100-0.1%
- Rated Life: 50000 Hours
- Construction: Die-cast aluminum with rotatable front face
- Fixed Beam high lumen output elements at Narrow Flood, Flood, or Wide Flood via factory installed TIR lens.
- Stealth armature with 360° horizontal rotation and 90° vertical aiming
- Accepts one lens and glare control accessory
- To enable access to VENTRIX element releasing tabs, maintain at least 3” of free channel space
- Driver concealed within the fixture
- Can be mounted on ceiling or wall vertically or horizontally
