VENTRIX Tunable White Niveous Pendants

NEW

NEW

Order Number:

model	size	watt	color temp & cri	delivered lumens	finish
S2PD02	2	12W	TWA - 1800-4000K - 90	1270	BK - Black
S2PD02	2	12W	TWA - 1800-4000K - 90	1270	WT - White
S2PD02	3	12W	TWA - 1800-4000K - 90	1270	BK - Black
S2PD02	3	12W	TWA - 1800-4000K - 90	1270	WT - White

Delivered Lumens: 1270lm
CCT: 1800-4000K
CRI: 90
Power: 12W
Input: 48 VDC
ELV Dimming: 100-0.1%
0-10V Dimming: 100-0.1%
TRIAC Dimming: 100-0.1%
DMX Dimming: 100-0.1%
Rated Life: 50000 Hours
Construction: Aluminum hardware with opal glass diffuser
Mouth blown etched opal glass provides even illumination
Thin powered cable provides an ultra-clean look
Suspension cable may be field shortened
Driver concealed within the VENTRIX adapter
To enable access to VENTRIX element releasing tabs, maintain at least 3” of free channel space
Driver concealed within the fixture
