Specifications
Order Number:
| model | beam | color temp & cri | 20w / 29w / 44w lumens | 20w / 29w / 44w cbcp | finish |
|---|---|---|---|---|---|
| R4RD1L | F - 45° | TWA - 1800K-4000K - 98 | 1050 / 1555 / 2205 | 1745 / 2550 / 3630 | BK - Black |
| R4RD1L | F - 45° | TWA - 1800K-4000K - 98 | 1050 / 1555 / 2205 | 1745 / 2550 / 3630 | CB - Copper Bronze |
| R4RD1L | F - 45° | TWA - 1800K-4000K - 98 | 1050 / 1555 / 2205 | 1745 / 2550 / 3630 | HZ - Haze |
| R4RD1L | F - 45° | TWA - 1800K-4000K - 98 | 1050 / 1555 / 2205 | 1745 / 2550 / 3630 | WT - White |
| R4RD1L | F - 45° | TWB - 2700K-6500K - 98 | 1080 / 1600 / 2235 | 1760 / 2575 / 3610 | BK - Black |
| R4RD1L | F - 45° | TWB - 2700K-6500K - 98 | 1080 / 1600 / 2235 | 1760 / 2575 / 3610 | CB - Copper Bronze |
| R4RD1L | F - 45° | TWB - 2700K-6500K - 98 | 1080 / 1600 / 2235 | 1760 / 2575 / 3610 | HZ - Haze |
| R4RD1L | F - 45° | TWB - 2700K-6500K - 98 | 1080 / 1600 / 2235 | 1760 / 2575 / 3610 | WT - White |
| R4RD1L | N - 25° | TWA - 1800K-4000K - 98 | 1110 / 1645 / 2325 | 3195 / 4755 / 6725 | BK - Black |
| R4RD1L | N - 25° | TWA - 1800K-4000K - 98 | 1110 / 1645 / 2325 | 3195 / 4755 / 6725 | CB - Copper Bronze |
| R4RD1L | N - 25° | TWA - 1800K-4000K - 98 | 1110 / 1645 / 2325 | 3195 / 4755 / 6725 | HZ - Haze |
| R4RD1L | N - 25° | TWA - 1800K-4000K - 98 | 1110 / 1645 / 2325 | 3195 / 4755 / 6725 | WT - White |
| R4RD1L | N - 25° | TWB - 2700K-6500K - 98 | 1120 / 1650 / 2315 | 3180 / 4695 / 6600 | BK - Black |
| R4RD1L | N - 25° | TWB - 2700K-6500K - 98 | 1120 / 1650 / 2315 | 3180 / 4695 / 6600 | CB - Copper Bronze |
| R4RD1L | N - 25° | TWB - 2700K-6500K - 98 | 1120 / 1650 / 2315 | 3180 / 4695 / 6600 | HZ - Haze |
| R4RD1L | N - 25° | TWB - 2700K-6500K - 98 | 1120 / 1650 / 2315 | 3180 / 4695 / 6600 | WT - White |
| R4RD1L | W - 60° | TWA - 1800K-4000K - 98 | 1070 / 1605 / 2255 | 1165 / 1735 / 2410 | BK - Black |
| R4RD1L | W - 60° | TWA - 1800K-4000K - 98 | 1070 / 1605 / 2255 | 1165 / 1735 / 2410 | CB - Copper Bronze |
| R4RD1L | W - 60° | TWA - 1800K-4000K - 98 | 1070 / 1605 / 2255 | 1165 / 1735 / 2410 | HZ - Haze |
| R4RD1L | W - 60° | TWA - 1800K-4000K - 98 | 1070 / 1605 / 2255 | 1165 / 1735 / 2410 | WT - White |
| R4RD1L | W - 60° | TWB - 2700K-6500K - 98 | 1110 / 1640 / 2300 | 1185 / 1745 / 2415 | BK - Black |
| R4RD1L | W - 60° | TWB - 2700K-6500K - 98 | 1110 / 1640 / 2300 | 1185 / 1745 / 2415 | CB - Copper Bronze |
| R4RD1L | W - 60° | TWB - 2700K-6500K - 98 | 1110 / 1640 / 2300 | 1185 / 1745 / 2415 | HZ - Haze |
| R4RD1L | W - 60° | TWB - 2700K-6500K - 98 | 1110 / 1640 / 2300 | 1185 / 1745 / 2415 | WT - White |
Features
- Delivered Lumens: 2325lm
- CBCP: 6725
- CCT: 1800K-4000K, 2700K-6500K
- CRI: 98
- Power: 20W, 29W, 44W
- Rated Life: 50000 Hours
- Construction: Durable die-cast aluminum construction
- Increased field angle for reduced scalloping
- Low ceiling and close-to-wall application
- Field selectable light engine height for cut-off angle adjustment (32° - 40°) and accessory use
- Compatible with wide range of accessories
