Specifications
Order Number:
| model | beam | color temp & cri | 20w / 29w / 44w lumens | 20w / 29w / 44w cbcp | finish |
|---|---|---|---|---|---|
| R4SD1L | F - 45° | TWA - 1800K-4000K - 98 | 1140 / 1685 / 2390 | 1890 / 2765 / 3935 | BK - Black |
| R4SD1L | F - 45° | TWA - 1800K-4000K - 98 | 1140 / 1685 / 2390 | 1890 / 2765 / 3935 | CB - Copper Bronze |
| R4SD1L | F - 45° | TWA - 1800K-4000K - 98 | 1140 / 1685 / 2390 | 1890 / 2765 / 3935 | HZ - Haze |
| R4SD1L | F - 45° | TWA - 1800K-4000K - 98 | 1140 / 1685 / 2390 | 1890 / 2765 / 3935 | WT - White |
| R4SD1L | F - 45° | TWB - 2700K-6500K - 98 | 1170 / 1730 / 2425 | 1905 / 2790 / 3910 | BK - Black |
| R4SD1L | F - 45° | TWB - 2700K-6500K - 98 | 1170 / 1730 / 2425 | 1905 / 2790 / 3910 | CB - Copper Bronze |
| R4SD1L | F - 45° | TWB - 2700K-6500K - 98 | 1170 / 1730 / 2425 | 1905 / 2790 / 3910 | HZ - Haze |
| R4SD1L | F - 45° | TWB - 2700K-6500K - 98 | 1170 / 1730 / 2425 | 1905 / 2790 / 3910 | WT - White |
| R4SD1L | N - 25° | TWA - 1800K-4000K - 98 | 1190 / 1760 / 2490 | 3420 / 5085 / 7195 | BK - Black |
| R4SD1L | N - 25° | TWA - 1800K-4000K - 98 | 1190 / 1760 / 2490 | 3420 / 5085 / 7195 | CB - Copper Bronze |
| R4SD1L | N - 25° | TWA - 1800K-4000K - 98 | 1190 / 1760 / 2490 | 3420 / 5085 / 7195 | HZ - Haze |
| R4SD1L | N - 25° | TWA - 1800K-4000K - 98 | 1190 / 1760 / 2490 | 3420 / 5085 / 7195 | WT - White |
| R4SD1L | N - 25° | TWB - 2700K-6500K - 98 | 1195 / 1765 / 2475 | 3405 / 5020 / 7060 | BK - Black |
| R4SD1L | N - 25° | TWB - 2700K-6500K - 98 | 1195 / 1765 / 2475 | 3405 / 5020 / 7060 | CB - Copper Bronze |
| R4SD1L | N - 25° | TWB - 2700K-6500K - 98 | 1195 / 1765 / 2475 | 3405 / 5020 / 7060 | HZ - Haze |
| R4SD1L | N - 25° | TWB - 2700K-6500K - 98 | 1195 / 1765 / 2475 | 3405 / 5020 / 7060 | WT - White |
| R4SD1L | W - 60° | TWA - 1800K-4000K - 98 | 1145 / 1715 / 2415 | 1245 / 1855 / 2575 | BK - Black |
| R4SD1L | W - 60° | TWA - 1800K-4000K - 98 | 1145 / 1715 / 2415 | 1245 / 1855 / 2575 | CB - Copper Bronze |
| R4SD1L | W - 60° | TWA - 1800K-4000K - 98 | 1145 / 1715 / 2415 | 1245 / 1855 / 2575 | HZ - Haze |
| R4SD1L | W - 60° | TWA - 1800K-4000K - 98 | 1145 / 1715 / 2415 | 1245 / 1855 / 2575 | WT - White |
| R4SD1L | W - 60° | TWB - 2700K-6500K - 98 | 1185 / 1755 / 2455 | 1265 / 1865 / 2585 | BK - Black |
| R4SD1L | W - 60° | TWB - 2700K-6500K - 98 | 1185 / 1755 / 2455 | 1265 / 1865 / 2585 | CB - Copper Bronze |
| R4SD1L | W - 60° | TWB - 2700K-6500K - 98 | 1185 / 1755 / 2455 | 1265 / 1865 / 2585 | HZ - Haze |
| R4SD1L | W - 60° | TWB - 2700K-6500K - 98 | 1185 / 1755 / 2455 | 1265 / 1865 / 2585 | WT - White |
Features
- Delivered Lumens: 2490lm
- CBCP: 7195
- CCT: 1800K-4000K, 2700K-6500K
- CRI: 98
- Power: 20W, 29W, 44W
- Rated Life: 50000 Hours
- Construction: Durable die-cast aluminum construction
- Increased field angle for reduced scalloping
- Low ceiling and close-to-wall application
- Field selectable light engine height for cut-off angle adjustment (32° - 40°) and accessory use
- Compatible with wide range of accessories
