Volta 4.5″ Tunable White Downlight Trim Round

NEW

NEW

model	beam	color temp & cri	20w / 29w / 44w lumens	20w / 29w / 44w cbcp	finish
R4RD2T	F - 45°	TWA - 1800K-4000K - 98	1040 / 1550 / 2185	1725 / 2545 / 3600	BK - Black
R4RD2T	F - 45°	TWA - 1800K-4000K - 98	1040 / 1550 / 2185	1725 / 2545 / 3600	BKWT - Black/White
R4RD2T	F - 45°	TWA - 1800K-4000K - 98	1040 / 1550 / 2185	1725 / 2545 / 3600	CB - Copper Bronze
R4RD2T	F - 45°	TWA - 1800K-4000K - 98	1040 / 1550 / 2185	1725 / 2545 / 3600	HZ - Haze
R4RD2T	F - 45°	TWA - 1800K-4000K - 98	1040 / 1550 / 2185	1725 / 2545 / 3600	HZWT - Haze/White
R4RD2T	F - 45°	TWA - 1800K-4000K - 98	1040 / 1550 / 2185	1725 / 2545 / 3600	WT - White
R4RD2T	F - 45°	TWB - 2700K-6500K - 98	1190 / 1760 / 2495	1905 / 2805 / 3990	BK - Black
R4RD2T	F - 45°	TWB - 2700K-6500K - 98	1190 / 1760 / 2495	1905 / 2805 / 3990	BKWT - Black/White
R4RD2T	F - 45°	TWB - 2700K-6500K - 98	1190 / 1760 / 2495	1905 / 2805 / 3990	CB - Copper Bronze
R4RD2T	F - 45°	TWB - 2700K-6500K - 98	1190 / 1760 / 2495	1905 / 2805 / 3990	HZ - Haze
R4RD2T	F - 45°	TWB - 2700K-6500K - 98	1190 / 1760 / 2495	1905 / 2805 / 3990	HZWT - Haze/White
R4RD2T	F - 45°	TWB - 2700K-6500K - 98	1190 / 1760 / 2495	1905 / 2805 / 3990	WT - White
R4RD2T	N - 25°	TWA - 1800K-4000K - 98	1080 / 1600 / 2295	3015 / 4465 / 6420	BK - Black
R4RD2T	N - 25°	TWA - 1800K-4000K - 98	1080 / 1600 / 2295	3015 / 4465 / 6420	BKWT - Black/White
R4RD2T	N - 25°	TWA - 1800K-4000K - 98	1080 / 1600 / 2295	3015 / 4465 / 6420	CB - Copper Bronze
R4RD2T	N - 25°	TWA - 1800K-4000K - 98	1080 / 1600 / 2295	3015 / 4465 / 6420	HZ - Haze
R4RD2T	N - 25°	TWA - 1800K-4000K - 98	1080 / 1600 / 2295	3015 / 4465 / 6420	HZWT - Haze/White
R4RD2T	N - 25°	TWA - 1800K-4000K - 98	1080 / 1600 / 2295	3015 / 4465 / 6420	WT - White
R4RD2T	N - 25°	TWB - 2700K-6500K - 98	1205 / 1775 / 2520	3310 / 4870 / 6915	BK - Black
R4RD2T	N - 25°	TWB - 2700K-6500K - 98	1205 / 1775 / 2520	3310 / 4870 / 6915	BKWT - Black/White
R4RD2T	N - 25°	TWB - 2700K-6500K - 98	1205 / 1775 / 2520	3310 / 4870 / 6915	CB - Copper Bronze
R4RD2T	N - 25°	TWB - 2700K-6500K - 98	1205 / 1775 / 2520	3310 / 4870 / 6915	HZ - Haze
R4RD2T	N - 25°	TWB - 2700K-6500K - 98	1205 / 1775 / 2520	3310 / 4870 / 6915	HZWT - Haze/White
R4RD2T	N - 25°	TWB - 2700K-6500K - 98	1205 / 1775 / 2520	3310 / 4870 / 6915	WT - White
R4RD2T	W - 60°	TWA - 1800K-4000K - 98	1050 / 1570 / 2215	1185 / 1765 / 2460	BK - Black
R4RD2T	W - 60°	TWA - 1800K-4000K - 98	1050 / 1570 / 2215	1185 / 1765 / 2460	BKWT - Black/White
R4RD2T	W - 60°	TWA - 1800K-4000K - 98	1050 / 1570 / 2215	1185 / 1765 / 2460	CB - Copper Bronze
R4RD2T	W - 60°	TWA - 1800K-4000K - 98	1050 / 1570 / 2215	1185 / 1765 / 2460	HZ - Haze
R4RD2T	W - 60°	TWA - 1800K-4000K - 98	1050 / 1570 / 2215	1185 / 1765 / 2460	HZWT - Haze/White
R4RD2T	W - 60°	TWA - 1800K-4000K - 98	1050 / 1570 / 2215	1185 / 1765 / 2460	WT - White
R4RD2T	W - 60°	TWB - 2700K-6500K - 98	1215 / 1825 / 2565	1305 / 1955 / 2730	BK - Black
R4RD2T	W - 60°	TWB - 2700K-6500K - 98	1215 / 1825 / 2565	1305 / 1955 / 2730	BKWT - Black/White
R4RD2T	W - 60°	TWB - 2700K-6500K - 98	1215 / 1825 / 2565	1305 / 1955 / 2730	CB - Copper Bronze
R4RD2T	W - 60°	TWB - 2700K-6500K - 98	1215 / 1825 / 2565	1305 / 1955 / 2730	HZ - Haze
R4RD2T	W - 60°	TWB - 2700K-6500K - 98	1215 / 1825 / 2565	1305 / 1955 / 2730	HZWT - Haze/White
R4RD2T	W - 60°	TWB - 2700K-6500K - 98	1215 / 1825 / 2565	1305 / 1955 / 2730	WT - White

model

beam

color temp & cri

20w / 29w / 44w lumens

20w / 29w / 44w cbcp

finish

R4RD2T

F - 45°

TWA - 1800K-4000K - 98

1040 / 1550 / 2185

1725 / 2545 / 3600

BK - Black

R4RD2T

F - 45°

TWA - 1800K-4000K - 98

1040 / 1550 / 2185

1725 / 2545 / 3600

BKWT - Black/White

R4RD2T

F - 45°

TWA - 1800K-4000K - 98

1040 / 1550 / 2185

1725 / 2545 / 3600

CB - Copper Bronze

R4RD2T

F - 45°

TWA - 1800K-4000K - 98

1040 / 1550 / 2185

1725 / 2545 / 3600

HZ - Haze

R4RD2T

F - 45°

TWA - 1800K-4000K - 98

1040 / 1550 / 2185

1725 / 2545 / 3600

HZWT - Haze/White

R4RD2T

F - 45°

TWA - 1800K-4000K - 98

1040 / 1550 / 2185

1725 / 2545 / 3600

WT - White

R4RD2T

F - 45°

TWB - 2700K-6500K - 98

1190 / 1760 / 2495

1905 / 2805 / 3990

BK - Black

R4RD2T

F - 45°

TWB - 2700K-6500K - 98

1190 / 1760 / 2495

1905 / 2805 / 3990

BKWT - Black/White

R4RD2T

F - 45°

TWB - 2700K-6500K - 98

1190 / 1760 / 2495

1905 / 2805 / 3990

CB - Copper Bronze

R4RD2T

F - 45°

TWB - 2700K-6500K - 98

1190 / 1760 / 2495

1905 / 2805 / 3990

HZ - Haze

R4RD2T

F - 45°

TWB - 2700K-6500K - 98

1190 / 1760 / 2495

1905 / 2805 / 3990

HZWT - Haze/White

R4RD2T

F - 45°

TWB - 2700K-6500K - 98

1190 / 1760 / 2495

1905 / 2805 / 3990

WT - White

R4RD2T

N - 25°

TWA - 1800K-4000K - 98

1080 / 1600 / 2295

3015 / 4465 / 6420

BK - Black

R4RD2T

N - 25°

TWA - 1800K-4000K - 98

1080 / 1600 / 2295

3015 / 4465 / 6420

BKWT - Black/White

R4RD2T

N - 25°

TWA - 1800K-4000K - 98

1080 / 1600 / 2295

3015 / 4465 / 6420

CB - Copper Bronze

R4RD2T

N - 25°

TWA - 1800K-4000K - 98

1080 / 1600 / 2295

3015 / 4465 / 6420

HZ - Haze

R4RD2T

N - 25°

TWA - 1800K-4000K - 98

1080 / 1600 / 2295

3015 / 4465 / 6420

HZWT - Haze/White

R4RD2T

N - 25°

TWA - 1800K-4000K - 98

1080 / 1600 / 2295

3015 / 4465 / 6420

WT - White

R4RD2T

N - 25°

TWB - 2700K-6500K - 98

1205 / 1775 / 2520

3310 / 4870 / 6915

BK - Black

R4RD2T

N - 25°

TWB - 2700K-6500K - 98

1205 / 1775 / 2520

3310 / 4870 / 6915

BKWT - Black/White

R4RD2T

N - 25°

TWB - 2700K-6500K - 98

1205 / 1775 / 2520

3310 / 4870 / 6915

CB - Copper Bronze

R4RD2T

N - 25°

TWB - 2700K-6500K - 98

1205 / 1775 / 2520

3310 / 4870 / 6915

HZ - Haze

R4RD2T

N - 25°

TWB - 2700K-6500K - 98

1205 / 1775 / 2520

3310 / 4870 / 6915

HZWT - Haze/White

R4RD2T

N - 25°

TWB - 2700K-6500K - 98

1205 / 1775 / 2520

3310 / 4870 / 6915

WT - White

R4RD2T

W - 60°

TWA - 1800K-4000K - 98

1050 / 1570 / 2215

1185 / 1765 / 2460

BK - Black

R4RD2T

W - 60°

TWA - 1800K-4000K - 98

1050 / 1570 / 2215

1185 / 1765 / 2460

BKWT - Black/White

R4RD2T

W - 60°

TWA - 1800K-4000K - 98

1050 / 1570 / 2215

1185 / 1765 / 2460

CB - Copper Bronze

R4RD2T

W - 60°

TWA - 1800K-4000K - 98

1050 / 1570 / 2215

1185 / 1765 / 2460

HZ - Haze

R4RD2T

W - 60°

TWA - 1800K-4000K - 98

1050 / 1570 / 2215

1185 / 1765 / 2460

HZWT - Haze/White

R4RD2T

W - 60°

TWA - 1800K-4000K - 98

1050 / 1570 / 2215

1185 / 1765 / 2460

WT - White

R4RD2T

W - 60°

TWB - 2700K-6500K - 98

1215 / 1825 / 2565

1305 / 1955 / 2730

BK - Black

R4RD2T

W - 60°

TWB - 2700K-6500K - 98

1215 / 1825 / 2565

1305 / 1955 / 2730

BKWT - Black/White

R4RD2T

W - 60°

TWB - 2700K-6500K - 98

1215 / 1825 / 2565

1305 / 1955 / 2730

CB - Copper Bronze

R4RD2T

W - 60°

TWB - 2700K-6500K - 98

1215 / 1825 / 2565

1305 / 1955 / 2730

HZ - Haze

R4RD2T

W - 60°

TWB - 2700K-6500K - 98

1215 / 1825 / 2565

1305 / 1955 / 2730

HZWT - Haze/White

R4RD2T

W - 60°

TWB - 2700K-6500K - 98

1215 / 1825 / 2565

1305 / 1955 / 2730

WT - White
