Specifications
Order Number:
| model | beam | color temp & cri | 20w / 29w / 44w lumens | 20w / 29w / 44w cbcp | finish |
|---|---|---|---|---|---|
| R4SAT | F - 45° | TWA - 1800K-4000K - 98 | 705 / 1045 / 1485 | 1380 / 2025 / 2890 | BK - Black |
| R4SAT | F - 45° | TWA - 1800K-4000K - 98 | 705 / 1045 / 1485 | 1380 / 2025 / 2890 | BKWT - Black/White |
| R4SAT | F - 45° | TWA - 1800K-4000K - 98 | 705 / 1045 / 1485 | 1380 / 2025 / 2890 | CB - Copper Bronze |
| R4SAT | F - 45° | TWA - 1800K-4000K - 98 | 705 / 1045 / 1485 | 1380 / 2025 / 2890 | HZ - Haze |
| R4SAT | F - 45° | TWA - 1800K-4000K - 98 | 705 / 1045 / 1485 | 1380 / 2025 / 2890 | HZWT - Haze/White |
| R4SAT | F - 45° | TWA - 1800K-4000K - 98 | 705 / 1045 / 1485 | 1380 / 2025 / 2890 | WT - White |
| R4SAT | F - 45° | TWB - 2700K-6500K - 98 | 730 / 1080 / 1505 | 1430 / 2095 / 2930 | BK - Black |
| R4SAT | F - 45° | TWB - 2700K-6500K - 98 | 730 / 1080 / 1505 | 1430 / 2095 / 2930 | BKWT - Black/White |
| R4SAT | F - 45° | TWB - 2700K-6500K - 98 | 730 / 1080 / 1505 | 1430 / 2095 / 2930 | CB - Copper Bronze |
| R4SAT | F - 45° | TWB - 2700K-6500K - 98 | 730 / 1080 / 1505 | 1430 / 2095 / 2930 | HZ - Haze |
| R4SAT | F - 45° | TWB - 2700K-6500K - 98 | 730 / 1080 / 1505 | 1430 / 2095 / 2930 | HZWT - Haze/White |
| R4SAT | F - 45° | TWB - 2700K-6500K - 98 | 730 / 1080 / 1505 | 1430 / 2095 / 2930 | WT - White |
| R4SAT | N - 25° | TWA - 1800K-4000K - 98 | 765 / 1140 / 1615 | 2680 / 3985 / 5645 | BK - Black |
| R4SAT | N - 25° | TWA - 1800K-4000K - 98 | 765 / 1140 / 1615 | 2680 / 3985 / 5645 | BKWT - Black/White |
| R4SAT | N - 25° | TWA - 1800K-4000K - 98 | 765 / 1140 / 1615 | 2680 / 3985 / 5645 | CB - Copper Bronze |
| R4SAT | N - 25° | TWA - 1800K-4000K - 98 | 765 / 1140 / 1615 | 2680 / 3985 / 5645 | HZ - Haze |
| R4SAT | N - 25° | TWA - 1800K-4000K - 98 | 765 / 1140 / 1615 | 2680 / 3985 / 5645 | HZWT - Haze/White |
| R4SAT | N - 25° | TWA - 1800K-4000K - 98 | 765 / 1140 / 1615 | 2680 / 3985 / 5645 | WT - White |
| R4SAT | N - 25° | TWB - 2700K-6500K - 98 | 775 / 1145 / 1605 | 2790 / 4120 / 5880 | BK - Black |
| R4SAT | N - 25° | TWB - 2700K-6500K - 98 | 775 / 1145 / 1605 | 2790 / 4120 / 5880 | BKWT - Black/White |
| R4SAT | N - 25° | TWB - 2700K-6500K - 98 | 775 / 1145 / 1605 | 2790 / 4120 / 5880 | CB - Copper Bronze |
| R4SAT | N - 25° | TWB - 2700K-6500K - 98 | 775 / 1145 / 1605 | 2790 / 4120 / 5880 | HZ - Haze |
| R4SAT | N - 25° | TWB - 2700K-6500K - 98 | 775 / 1145 / 1605 | 2790 / 4120 / 5880 | HZWT - Haze/White |
| R4SAT | N - 25° | TWB - 2700K-6500K - 98 | 775 / 1145 / 1605 | 2790 / 4120 / 5880 | WT - White |
Features
- Delivered Lumens: 1615lm
- CBCP: 5880
- CCT: 1800K-4000K, 2700K-6500K
- CRI: 98
- Power: 20W, 29W, 44W
- Rated Life: 50000 Hours
- Construction: Durable die-cast aluminum construction
- Center beam alignment retained throughout adjustment range
- 0-45° vertical and 365° horizontal lockable hot aiming
- Indexed vertical scaling for precise and accurate alignment
- Compatible with a wide range of accessories
