Specifications Limited Availability, Consult Factory
Limited Availability, Consult Factory
Order Number:
| system type & voltage | model | color temp & cri | lumens | finish |
|---|---|---|---|---|
| MO - 120 VAC | 3020W | 930 - 3000K - 90 | 925 | WT - White |
| MO - 120 VAC | 3020W | 935 - 3500K - 90 | 1030 | BK - Black |
| MO - 120 VAC | 3020W | 935 - 3500K - 90 | 1030 | WT - White |
| MO - 120 VAC | 3020W | 940 - 4000K - 90 | 1035 | BK - Black |
| MO - 120 VAC | 3020W | 940 - 4000K - 90 | 1035 | WT - White |
Features
- Delivered Lumens: Up to 1035lm
- CCT: 3000K, 3500K, 4000K
- CRI: 90
- Power: 20W
- Input: 120 VAC, 50/60Hz
- ELV Dimming: 100-5%
- Rated Life: 60000 Hours
- Construction: Die-cast aluminum
- Asymmetrical beam distribution for even wall illumination
- 350° horizontal rotation and 90° vertical aiming
- Economical peformance luminaire with integral LED and driver
- Driver concealed within the fixture
- Can be mounted on ceiling or wall in all orientations
Line Drawing
