Specifications
Order Number:
| model & voltage | color temp & cri | lumens | finish |
|---|---|---|---|
| WL-LED200TR - 120 VAC | 2700K - 90 | 72 | WT - White on Aluminum |
| WL-LED200TR - 120 VAC | Amber - 90 | 72 | WT - White on Aluminum |
| WL-LED200TR - 120 VAC | Blue - 90 | 72 | WT - White on Aluminum |
| WL-LED200TR - 120 VAC | 3000K - 90 | 72 | WT - White on Aluminum |
| WL-LED200TR - 120 VAC | Red - 90 | 72 | WT - White on Aluminum |
Features
- Delivered Lumens: 72lm
- CCT: 2700K, 3000K, Amber, Blue, Red
- CRI: 90
- Power: 3.3W
- Input: 120 VAC, 50/60Hz
- ELV Dimming: 100-10%
- Rated Life: 50000 Hours
- Construction: Die-cast corrosion resistant aluminum alloy
- Can be painted to match the color of the surface
- Low profile, flush to wall aesthetics with no visible hardware
- Balanced lighting, free of shadows with minimum glare
- Up to 200 fixtures can be connected in parallel
Line Drawing
