Ellaria Bath & Wall WAC HOME

NEW

Order Number:

model & size	color temp	finish	led watts	led lumens	delivered lumens
WS104625 - 25"	1800-4000K for WAC Home System	BK - Black	26.4W	2966	1197
WS104625 - 25"	1800-4000K for WAC Home System	BN - Brushed Nickel	26.4W	2966	1197

Delivered Lumens: 1197lm
CCT: 1800-4000K for WAC Home System
CRI: 90
Power: 26.4W
Input: 120-277V, 50/60Hz
ELV Dimming: 100-10%
TRIAC Dimming: 100-10%
Rated Life: 50000 Hours
Construction: Aluminum body with mouth blown opal glass
3000K (Default)
1800-4000K for WAC HOME SYSTEM ONLY
Standard dimming function available for default setting if not using WAC HOME SYSTEM
Can be mounted on wall in all orientations
Driver concealed within the canopy
Can be mounted on wall in all orientations

When fixture is connected to TRIAC/ ELV dimmer, fixture will fully dim while maintaining 3000K color temp.
When fixture is connected to WAC Home Gateway and WAC Home Wallstation Tunable white and Dim-to-Warm functions are activated.
Use the MyWAC app for additional WAC Home functions.
Additional WAC Home compatible products
Learn more about WAC Home Technology
